Xingyi CD-553B Industrial Dust Collector – High Performance Auto-Cleaning Vacuum
The Xingyi CD-553B is a state-of-the-art industrial dust collector, designed to deliver superior dust extraction performance in heavy-duty environments. Featuring a powerful 7.5 kW motor, an automatic jet-pulse filter cleaning system, and a high-efficiency HEPA filtration system, this vacuum is ideal for maintaining a dust-free workspace while ensuring high air quality. Whether used alongside floor grinding machines or as a standalone dust control solution, the CD-553B provides unmatched efficiency, durability, and ease of use.
Key Features & Specifications
- Motor Power: 7.5 kW (10 HP)
- Additional Compressor Power: 1.5 kW
- Voltage Options: 380V (3-phase) / 220V (3-phase)
- Vacuum Pressure: 40 kPa (400 mbar)
- Maximum Airflow: 1,100 m³/h (648 CFM)
- Filtration System: HEPA H13 filter with 3.36㎡ filtration area
- Filter Cleaning Mechanism: Automatic jet-pulse system for continuous operation
- Hose Compatibility: 50 mm / 63 mm / 80 mm diameter options
- Dust Collection Method: Continuous drop-down bag system for easy disposal
- Machine Dimensions (L × W × H): 1,370 × 645 × 1,490 mm (without cyclone bucket)
- Machine Dimensions (L × W × H): 1,798 × 645 × 1,490 mm (with cyclone bucket)
- Machine Weight: 235.5 kg
Key Benefits of the Xingyi CD-553B
- Powerful Suction for Maximum Dust Collection
Equipped with an inverter-controlled motor, the CD-553B offers over 40% greater airflow compared to traditional dust collectors. With a high vacuum pressure of 40 kPa, it effectively captures fine dust, ensuring cleaner air and preventing dust build-up on job sites.
- Advanced HEPA Filtration System
The HEPA H13 filter captures 99.97% of particles as small as 0.3 microns, including silica dust, ensuring a healthier workspace by removing airborne contaminants. The large 3.36㎡ filtration area increases efficiency and prolongs filter lifespan.
- Automatic Jet-Pulse Cleaning System
A fully automated jet-pulse system cleans the filters every 6 seconds, preventing clogging and maintaining peak suction power without requiring manual intervention. This ensures uninterrupted operation and reduces downtime.
- Soft Start & Energy Efficiency
The soft-start feature gradually accelerates the fan, reducing energy consumption and preventing electrical overloads. This prolongs motor life and makes the machine suitable for both small and large-scale operations.
- Intelligent Control System with HMI Feedback
An HMI (Human-Machine Interface) display allows real-time monitoring of operating voltage, current, and fault signals. If an issue arises (e.g., overload, phase loss), the system provides instant feedback, allowing operators to take corrective action quickly.
- Versatile Hose Compatibility & Adjustable Suction Power
The vacuum supports multiple hose diameters (50 mm, 63 mm, 80 mm), allowing it to adapt to various applications, from fine dust collection to large debris removal. The variable airflow control ensures optimized suction power based on the task at hand.
- Low Noise Operation
With an integrated silencer and an internally smooth vacuum chamber, the CD-553B operates at a noise level of 80 dB during vacuuming and 85 dB during dust cleaning, significantly reducing workplace noise pollution.
- Cyclone Pre-Separator for Extended Filter Life
The optional cyclone separator removes 80-90% of dust before it reaches the filter, reducing clogging and extending filter lifespan. This ensures long-term cost savings on maintenance and replacement filters.
- Continuous Drop-Down Bag System for Easy Dust Disposal
Unlike traditional vacuum cleaners that require manual bin emptying, the drop-down bag system ensures hygienic, dust-free disposal, making it perfect for environments where silica dust exposure must be minimized.
Ideal Applications
The Xingyi CD-553B Industrial Dust Collector is designed for demanding environments that require continuous dust extraction, including:
- Concrete Grinding & Polishing – Essential for use with floor grinders to control dust on large-scale projects.
- Construction & Renovation Sites – Effectively captures airborne particles from demolition, cutting, and sanding.
- Manufacturing & Industrial Facilities – Maintains clean workspaces in factories, workshops, and production lines.
- Warehouse & Logistics Centers – Keeps warehouse floors and air quality free from dust buildup.
- Silica Dust Control Compliance – Helps businesses meet OSHA & environmental health regulations for dust exposure limits.
Why Choose the Xingyi CD-553B?
- Stronger Suction Power – 40% more airflow than standard vacuum systems.
- Lower Maintenance Costs – Automatic self-cleaning system extends filter life.
- User-Friendly Operation – HMI control panel provides real-time system feedback.
- Health & Safety Compliance – HEPA filtration ensures clean air and safe disposal.
- Built for Heavy Duty Use – Robust construction and durable components ensure longevity.
The Xingyi CD-553B is a next-generation industrial vacuum cleaner that combines power, efficiency, and automation to deliver superior dust collection performance. Whether you’re grinding concrete, maintaining a construction site, or ensuring compliance with silica dust regulations, this auto-cleaning vacuum system is the perfect solution for cleaner, healthier, and more efficient work environments.
Contact us today to learn more or request a quote!
